Overview
300Mbps Wireless N Ceiling Mount Access Point
Flexible Placement with Easy mounting design & PoE
The EAP's "ceiling lamp" appearance and easy mounting design with chassis make it easy to be integrated seamlessly into any wall or ceiling surface to blend in with most interior decorations. EAP110 support Passive PoE to make deployment effortless and flexible.
Business Class Wireless with Powerful Hardware
EAP110 features 802.11n Wi-Fi and 2×2 MIMO technology, wireless speeds of up to 300Mbps
With Qualcomm Atheros 560MHz chipsets, EAP ensures incredible wireless coverage and reliability
Free Centralised Management Platform with EAP Controller Software
EAP Controller Software enables users to manage hundreds of TP-LINK's EAPs simultaneously and easily from PCs in the network, making centralised business Wi-Fi management efficient, visible and more cost-effective like never before.
Efficient Guest Authentication Captive Portal
Captive portal provides one convenient method of authentication for Wi-Fi guests. A captive portal requires users to perform certain actions before network access is allowed. The required action must be verified by an external portal server or customised database by the administrator, which can be simply viewing and agreeing to an acceptable use policy, or entering a user ID and password.
Applicable to Multi-user Environment, Designed for Business Performance
With easy mounting design, PoE power supply, Cluster feature, Centralised management software, Captive portal, Auto RF management, and business hardware, EAP series are specially designed for the high-density, most demanding business environments, including schools, hotels and enterprises.
Features
- EAP Controller Software enables administrators to easily manage hundreds of EAPs
- Support Passive PoE for convenient and affordable installation
- Simple mounting design to easily mount to a wall or ceiling
- 300Mbps wireless data rate for uninterrupted wireless connection
- Captive portal provides one convenient method of authentication for Wi-Fi guests
- Rate limit on per SSID to restrict the bandwith of each client
- Access Control restricts or allows the client to access the specified network segment
- Reboot Schedule enables all the APs to be rebooted automatically within a specified time
- WPA/WPA2-enterprise, 802.1X with RADIUS secure authentication and rogue access point detection ensure the security of WLAN
- Multi-SSID divides multiple wireless network for different users
- Load balance ensures large numbers of users have smooth network experiences in large business networks
- Compatible with 802.11 b/g/n products
- Adopts Low Smoke Zero Halogen (LSOH) materials for UL2043 compliance
- Multiple operating modes satisfy different application conditions including managed AP and standalone AP modes
- QoS function prioritises data, voice, and video applications to ensure time-sensitive traffic takes priority over all other traffic
- Prevents dust from dropping onto the PCB through bypass louver, which ensures long-term, unhindered operation.
Specifications
Specifications
| HARDWARE FEATURES | Interface | Fast Ethernet (RJ-45) Port × 1 (Support Passive PoE) |
|---|
| Button | Reset |
| Power Supply | 24V DC / 1A Passive PoE Supply |
| Power Consumption | 7.7W |
| Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Dimensions (W×D×H) | 180mm × 180mm × 47.5mm (7.1″ × 7.1″ × 1.9″) |
| Antenna Type | Internal 2 × 3dBi Omni |
| Mounting | Ceiling / Wall Mounting (Kits included) |
| Physical Security Lock | Kensington Lock Slot |
| Watch Dog | Yes |
| WIRELESS FEATURES | Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
|---|
| Frequency | 2.4-2.4835GHz |
| Signal Rate | - 11n: Up to 300Mbps (dynamic)
- 11g: Up to 54Mbps (dynamic)
- 11b: Up to 11Mbps (dynamic)
|
| Reception Sensitivity | - 300M: −71dBm @ 10% PER
- 150M: −75dBm @ 10% PER
- 54M: −78dBm @ 10% PER
- 11M: −93dBm @ 8% PER
- 6M: −92dBm @ 10% PER
- 1M: −96dBm @ 8% PER
|
| Wireless Functions | - Multiple SSIDs (Up to 8 SSIDs)
- Enable/Disable Wireless Radio
- Automatic Channel Assignment
- Transmit Power Control (Adjust Transmit Power on dBm)
- QoS (WMM)
- Rate Limit
- Reboot Schedule
- Wireless Schedule
- Wireless Statistics based on SSID/AP/Client
|
| Wireless Security | - Captive Portal Authentication
- Access Control
- Wireless Mac Address Filtering
- Wireless Isolation Between Clients
- SSID to VLAN Mapping
- Rogue AP Detection
- 802.1X Support
- 64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK /WPA2-PSK
|
| Transmission Power | |
| MANAGEMENT | EAP Controller Software | Yes |
|---|
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1,v2c |
| System Logging Local/Remote Syslog | Local/Remote Syslog |
| Telnet | Yes |
| Web-based Management | HTTP/HTTPS |
| Environment | Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
|---|
| Storage Temperature | −40°C ~ 70°C (−40°F ~ 158°F) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
OTHERS | Certification | CE, FCC, RoHS | | Package Contents | - 300Mbps Wireless N Ceiling Mount Access Point EAP110
- Passive PoE Adapter
- Power Cord
- Mounting Kits
- Resource CD
- Installation Guide
|
| System Requirements | Microsoft Windows 10/8/7/Vista/XP |
