Android APP Mobile Phone Remote Optical Isolation Switch for Motor LED Light

Android APP Mobile Phone Remote Optical Isolation Switch for Motor LED Light

Price	$43.77
	Collect 43 Everyday Rewards points Plus get 2x points on every order when you spend $100+ Ends 11:59pm 26/03/2025. Exclusions & T&Cs apply Log in to MyDeal to link your card
Shipping	Free Shipping
	24-48 hour dispatch See delivery details

Take 10% Off Purchases Over $29

Exclusive to Zhongshan Junchang Mould Co Ltd (Direct Import) products only. Expires 11.59pm 30/03/2025. Excludes Shipping. Everyday Rewards points will be collected on your total purchase less any discounts. T&C's apply.

Copy code 2BFLA

Quantity

Add to wishlist

Description:

1 Operating voltage: power supply 1, DC 6-25V; power supply 2,C 5V
2 Operating Current: Standby 11MA, Relay Open 45MA (voltage DC 12V)
3 Bluetooth V2.1 + EDR, Class 2
4 2.4GHz-2.48GHz unlicensed ISM band
5send commands via Android Bluetooth APP control relay turned on and off (we provide Bluetooth APP, you can also use your own APP to control relays, sending commands to control),It can also be triggered by an external pulse signal.
6 ''Momentary'' ''Self-locking'' ''open'' ''close'' 4 Commands
7 External trigger input, opto-isolated switch, low pulse inputs.
8 size (including housing) 81 * 50 * 32
9 Weight : 66g
10 Relay Maximum load:10A/250VAC ,10A/125VAC,10A /30VDC, 10A /28VDC ,10A /12VDC

Typical applications:

Home lighting system
Remote control switch
Remote locking
Smart Home / Home Automation
DC 12V LED lighting
Fluorescent lamp
Phone APP
12V DC Motor
Fluorescent lamp
Automotive electronics
PLC

Package inlcuded:1 PCS DC 5V-25V 1 Channel Bluetooth Relay Module

GTIN: 774048926218
