The Access Point WiFi 6 Pro (U6 Pro) is a high-performance, dual-band WiFi 6 access point ideal for home and office use. The U6 Pro is capable of reaching an aggregate throughput rate up to 5.3 Gbps with its 5 GHz (4x4MIMO) and 2.4 GHz (2x2 MIMO) bands, which allows it to support over 300 concurrently connected clients while maintaining an even, reliable wireless experience across your entire network. It can also isolate your guest traffic to ensure optimal security and speed. The U6 Pro also operates at full 4x4 MIMO with 160 MHz channels to create high-capacity wireless uplinks and facilitate faster data transfer. It can be set up in minutes and fully managed withthe UniFi Network application*.
Features:
Mechanical | |
---|---|
Dimensions | Ø197 x 35 mm (Ø7.76 x 1.38") |
Weight | Without mount: 460 g (1.01 lb) With mount: 600 g (1.32 lb) |
Enclosure material | Plastic |
Mounting material | SGCC steel |
Weatherproofing | IP54 |
Hardware | |
Management interfaces | Ethernet Bluetooth |
Networking interface | (1) GbE RJ45 port |
Button | Factory reset |
LED* | White/blue *Due to chip supply shortages, the U6 AP's LED has been limited to only white and blue color modes. |
Power method | 802.3at PoE+ |
Power supply | UniFi PoE switch 48V, 0.5A PoE adapter (not included) |
Supported voltage range | 44 to 57VDC |
Max. power consumption | 13W |
Max. TX power 2.4 GHz 5 GHz | 22 dBm 26 dBm |
MIMO 2.4 GHz 5 GHz | 2 x 2 (UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO) |
Throughput rate 2.4 GHz 5 GHz | 573.5 Mbps 4.8 Gbps |
Antenna gain 2.4 GHz 5 GHz | 4 dBi 6 dBi |
Mounting | Wall/ceiling (included) |
Operating temperature | -30 to 60°C (-22 to 140° F) |
Operating humidity | 5 - 95% noncondensing |
Certifications | CE, FCC, IC |
Software | |
WiFi standards | 802.11a/b/g WiFi 4/WiFi 5/WiFi 6 |
Wireless security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
BSSID | 8 per radio |
VLAN | 802.1Q |
Advanced QoS | Per-user rate limiting |
Guest traffic isolation | Supported |
Concurrent clients | 300+ |
Zero wait DFS | Yes* *Supported with upcoming firmware versions |
Supported Data Rates | |
802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11b | 1, 2, 5.5, 11 Mbps |
802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11n (WiFi 4) | 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) |
802.11ac (WiFi 5) | 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) |
802.11ax (WiFi 6) | 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) |
