Doss LCT8 Pro Coax & Lan Cable Tester Locates Distance to the Fault/Coaxial/Wire

Doss LCT8 Pro Coax & Lan Cable Tester Locates Distance to the Fault/Coaxial/Wire

Price
$233.10
Collect 233 Everyday Rewards points
Log in to MyDeal to link your card
Shipping
Free Shipping

Quantity
Maximum item limit (218) has been reached.


The LCT8 is a great tester for people doing communicationinstallations and maintenance, as it provides quick verification of several common types of communication problems in structured LAN wiring, coaxial cabling and telephone wiring.



  • Find the open circuits, short circuits, jumpers, crossed or split pairs in coax and UTP cables.
  • Identifies and locates the distance to an open or a short in seconds
    • Time-domain reflectometer (TDR)
  • Identify cables using upto 8 (optional) remote terminators
    • Remote adaptors require no extra power
    • 1x remote terminator supplied with LCT8
  • Low battery indication.
  • Measures cable length in a box, on a spool, or in a wall. Know how much cable you have left on a spool before beginning your pulls.
  • Check for wiring errors in: LAN UTP cables, coaxial cables and telephone lines, such as:
    • open circuit,
    • short circuit,
    • jumper wire,
    • reverse connection,
    • cross talk interface or,
    • split pairs.
  • Locate the wiring or connection error.
  • Dynamically calibrate cable length and make length measurement as accurate as 97%.
  • Simple and easy to use 144 x 64 Dots FSTN LCD screen display test results.
  • Portable unit with long battery life.
  • Automatic time delay shut off.
  • Measure length and pair without the need for remote terminator.
  • 1x Remote terminator with audible alert supplied.
  • Self-checking function and automatic compensation for any change in battery capacity or ambient temperature.
  • Dimensions: 195 x 93 x 38mm (LCD display: 69 x 38mm)
  • Locate/Identify cables with up to 8 remote passive test jacks
    • Note: Only 1x passive terminator supplied (ID01)
    • 7x extra optional passive terminators available: LCT8RM

Specifications:

  • Display 4x16 Character LCD lattice.LCD module:70.6 x 60mm (valid visual field 60 x 32.6mm)
  • Connector Type RJ45 / RJ12 / RJ11 & F-connector
  • Button (1)Lan, (2)Tel, (3)Coax, (4)Tone, (5)Length, (6)Test, (7)Power
  • Cable Type Shielded or unshielded, CAT-6, CAT5e, CAT5, CAT4, CAT3 and coax.
  • Error Status Open circuit, short circuit, jumper wire, reverse,connection or cross-talk interference and split pairs.
  • Measure Types Measures cable length via TDR.Checks and verifies wire tap.Generates four different tracing tones to help identify users.
  • Cable Length & Accuracy Accuracy of the length measurement is ± 5%
  • Length: 1 ~ 350 meters (3~12000 feet)
  • Minimum cable length for testing twin pairs 1 metre (3 feet)
  • Power Source 9 volt alkaline battery.(included)
  • Turns off automatically Auto-off in any module and low power consumption for long battery life.
  • Input protection Protection against excess voltage, transients ringer signal.
  • Dimensions 195mm(L), 90mm(W), 40mm(H)
  • Enviromental Operating temp: 0 to 50 CStorage temp: -10 to 60 CHumidity: 10% to 90% non condensing.
  • Accessories Tool bag, F to BNC adapter x 2

Warning

The LCT8 should not be used on an 'active' circuit, since it will interfere with the signal and affect the testing judgments.

This item comes with 12 month Warranty
