Victron Energy MPPT 100/20 20A SmartSolar Solar Charge Controller 48v
3x

Victron Energy MPPT 100/20 20A SmartSolar Solar Charge Controller 48v

Hurry! 7 items left!
Price
$271
Collect 813 Everyday Rewards points
Score 3x points on every order
Ends 11:59pm 03/01/2025. Exclusions & T&Cs apply
Log in to MyDeal to link your card
Shipping
Free Shipping

24-48 hour dispatch
Quantity
Maximum item limit (7) has been reached.


SmartSolar Charge controller featuring:

  • Bluetooth enabled
  • Day/night timing and light dimming option
  • Ultra-fast Maximum Power Point Tracking (MPPT)
  • Intelligent battery management
  • 48v

Model: SmartSolar MPPT 100/20

Charge current: 20 A
Maximum PV Open Circuit Voltage: 100V
Maximum PV Power: 1160W
Battery voltage (nominal): 48V
Charge algorithm: Multi-stage adaptive

Ultra-fast Maximum Power Point Tracking (MPPT)

Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.

Load output

Over-discharge of the battery can be prevented by connecting all loads to the load output. The load output will disconnect the load when the battery has been discharged to a pre-set voltage. Alternatively, an intelligent battery management algorithm can be chosen: see Battery Life. The load output is short circuit proof. Some loads (especially inverters) can best be connected directly to the battery, and the inverter remote control connected to the load output. A special interface cable may be needed, please see the manual.

Battery Life: intelligent battery management

When a solar charge controller is not able to recharge the battery to its full capacity within one day, the result is often that the battery will continually be cycled between a ‘partially charged’ state and the ‘end of discharge’ state. This mode of operation (no regular full recharge) will destroy a lead-acid battery within weeks or months.

The Battery Life algorithm will monitor the state of charge of the battery and, if needed, day by day slightly increase the load disconnect level (i.e. disconnect the load earlier) until the harvested solar energy is sufficient to recharge the battery to nearly the full 100%. From that point onwards the load disconnect level will be modulated so that a nearly 100% recharge is achieved about once every week.

Programmable battery charge algorithm

Day/night timing and light dimming option

Programming, real-time data and history display options

- Modern Apple and Android smartphones, tablets, macbooks and other devices

Additional Information
    Part Number SCC110020160R
    Manufacturer

    Victron Energy




    Downloads
        BlueSolar and SmartSolar Charge Controller MPPT - Overview
    SmartSolar MPPT 75/10, 75/15, 100/15, 100/20 & 100/20-48V
    SKU: SCC110020160R
