Powertech IP67 Rated 12-24V 10A PWM Solar Charge Controller with Timer Function

12/24V 10A PWM SOLAR CHARGE CONTROLLER WITH TIMER FUNCTION IP67

A highly efficient fully automatic 12/24V PWM solar charge controller that adopts the most advanced digital technology which increases battery lifetime and improves solar system performance. With a robust industrial housing and IP67 protection this charge controller is suited to mostapplications especially extreme outdoor environments where corrosion, dust and water ingress are prevalent. Capable of automatically detecting day/night it comes with an inbuilt timer which can be set to operate loads at specific intervals or manually in the night.
Features:

• High efficient PWM charging
•  Automatically recognizes day/night
• LED indicators for PV and battery status
• Industrial design, wide application range
• Intelligent timer function with 1 to 13 hours’ option
• IP67 protection
• PV reverse polarity protection
• Battery overcharge, over discharge, reverse polarity and overheating protection
• Load overload and short circuit protection

Specifications:

• Voltage: 12/24VDC Automatic
• Max. PV Input Voltage: 50V
• Current: 10A
• Equalize Voltage: 14.8V(12V);29.6V(24V)
• Boost Voltage: 14.4V(12V);28.8V(24V)
• Float Voltage: 13.7V(12V);27.4V(24V)
• Low Voltage Reconnect Voltage: 12.6V(12V);25.2V(24V)
• Low Voltage Disconnect Voltage: 11.2V(12V);22.4V(24V)
• Self-consumption:
• 12V: ≤4.58mA
• 24V: ≤6.01mA
• Temperature compensation coefficient:-5mV/°C/2V (25°C)
• Working temperature: -35°C - 55°C
• IP Rating: IP67
• Mounting Dimension: 101mm
• Mounting hole size: Φ5
• Power cable: PV/BAT/LOAD:4.0mm2
• Weight: 410g
• Dimensions: 109(W) × 75(H) × 26(D)mm
