Grundfos UPS32-80-N-180 Hot Water Circulator Pump (95906448) 240V 220 Watt 32MM

Speed no

3

Head max

60 dm

TF class

110

Approvals on nameplate

CE,EAC,WEEE,RCM

Materials

Pump housing

Stainless steel

DIN W.-Nr. 1.4301

Impeller

Composite, PES/PP

Installation

Amb. max at 80 dgr C liquid

40 °C

Maximum operating pressure

10 bar

Pipe connection

G 2

Pressure rating

PN 10

Port-to-port length

180 mm

Liquid

Pumped liquid

Water

Liquid temperature range

-25 .. 110 °C

Selected liquid temperature

60 °C

Density

983.2 kg/m³

Electrical data

Power input in speed 1

135 W

Power input in speed 2

200 W

Max. power input

220 W

Mains frequency

50 Hz

Rated voltage

1 x 230 V

Current in speed 1

0.6 A

Current in speed 2

0.9 A

Current in speed 3

0.98 A

Capacitor size - run

4 µF

Enclosure class (IEC 34-5)

X2D

Insulation class (IEC 85)

F

Built-in motor protection

CONTACT

Thermal protec

internal

Controls

Pos term box

9H

Others

Net weight

4.9 kg

Gross weight

5.2 kg

Shipping volume

0.008 m³

Danish VVS No.

380648100

Swedish RSK No.

5803139

Finnish LVI No.

4615612

Country of origin

RS

Custom tariff no.

8413709062
