The Dream Machine Special Edition (UDM SE) is an enterprise-grade UniFi OS Console capable of helping home and business owners alike seamlessly scale and manage their networks with high-speed, dual-WAN connectivity (10G SFP+ and 2.5GbE RJ45 ports), a Gigabit, PoE switch, and a network video recorder (NVR) with 128 GB of internal storage.
Powered by UniFi OS, the UDM SE gives you full control of all your UniFi devices, including access points, Protect cameras, Talk phones, and Access readers. It's also a future-proof console since it will be able to run all upcoming UniFi OS applications. Engineered for end-to-end simplicity, the UDM SE features an integrated Bluetooth radio that streamlines the initial setup and configuration process, which can be completed in minutes with the UniFI Network application (web or mobile).
Mechanical | |
---|---|
Dimensions | 442.4mm × 43.7mm × 285.6mm (17.42″ × 1.72″ × 11.24″) |
Weight | 4.95kg (10.91lb) |
Enclosure Materials | Aluminium CNC, SGCC steel |
Mount Material | SGCC steel rack mount |
Hardware | |
Processor | Quad-Core ARM® Cortex® −A57 at 1.7 GHz |
System Memory | 4 GBDDR4 |
On-board Storage | 16GB eMMC |
IDS/IPS Throughput | 3.5 Gbps* *Measured with iPerf3 |
Max. Power Consumption (excluding PoE output) | 50W |
Power Method | 1 × Universal AC input, 100-240V AC, 4.4A Max, 50/60Hz 1 × USP-RPS DC input, 52V DC, 3.94A |
Power Supply | AC/DC, Internal, 240W |
Supported Voltage Range | 100V to 240V AC |
Management Interfaces | Ethernet |
Networking Interfaces | 1 × WAN: 2.5 GbE RJ45 port |
SFP+ Interfaces | 1 × WAN: 10G SFP+ 1 × LAN: 10G SFP+ |
PoE Interfaces | 2 × PoE+ IEEE 802.3at (pair A 1, 2+; 3, 6−) 6 × PoEIEEE 802.3af (pair A 1, 2+; 3, 6−) |
Max. PoE Wattage Per Port by PSE 802.3af | 15.4W |
Max. PoE Wattage Per Port by PSE 802.3at | 30W |
Voltage Range 802.3af Mode | 44V to 57V |
Voltage Range 802.3at Mode | 50V to 57V |
ESD/EMP Protection | Air: ±15kV |
LCM Display | 1 × 1.3″ touchscreen Bootup Animation: bootup in progress Firmware Upgrade Icon: firmware upgrading |
Button | Factory Reset |
Operating Temperature | −10°C to 40°C (14°F to 104°F) |
Operating Humidity | 5 - 95% non-condensing |
Certifications | CE, FCC, IC |
LEDs | |
Ethernet | White: link/activity |
SFP+ | White: link/activity |
HDD | White: disk activity Amber: disk error |
RPS | Blue: ready |
