Mitsubishi Pajero Sport QE 2016+ Wiring Diagrams

Mitsubishi Pajero Sport QE 2016+ Wiring Diagrams

Hurry! 17 items left!

Price	$24.01
	Collect 24 Everyday Rewards points Log in to MyDeal to link your card
Shipping	$9.00 Australia-wide (per item)
	See delivery details

Quantity

Add to wishlist

Mitsubishi Pajero Sport QE 2016 +

Includes:

1. Wiring Circuit Diagrams
2. Configuration Diagrams
3. Component Locations
4. General Vehicle Information
5. User Manual
6. Audio User Manual
7. Connect User Manual

Engines Covered:

2.4L 4G6 ENGINE
2.4L 4N1 ENGINE
2.5L 4D5 ENGINE
3.0L 6B3 ENGINE

Transmissions Covered:

8-SPEED AUTOMATIC TRANSMISSION
6-SPEED MANUAL TRANSMISSION
5-SPEED AUTOMATIC TRANSMISSION
5-SPEED MANUAL TRANSMISSION

1. Wiring Circuit Diagrams include:

CD AUDIO, DISPLAY AUDIO (CD TYPE)
ACCESSORY SOCKET
ACTIVE STABILITY & TRACTION CONTROL SYSTEM (ASTC)
HILL START ASSIST (HSA) AND HILL DESCENT CONTROL (HDC)
ADAPTIVE CRUISE CONTROL SYSTEM (ACC)
FORWARD COLLISION MITIGATION SYSTEM (FCM)
ANTI-SKID BRAKING SYSTEM (ABS)
AUTOMATIC ANTI-DAZZLING MIRROR
AUTOMATIC TRANSMISSION
BACK-UP LAMP
BLIND SPOT WARNING SYSTEM (BSW)
CENTRAL DOOR LOCKING SYSTEM
CENTRALIZED JUNCTION
CHARGING SYSTEM
CIGARETTE LIGHTER
CONTROLLER AREA NETWORK (CAN)
COOLER AND REAR COOLER
CRUISE CONTROL SYSTEM
DAYTIME RUNNING LAMP (DRL)
DISPLAY AUDIO (DVD TYPE)
DOOR AJAR WARNING BUZZER
DOOR COURTESY LAMP
ELECTRIC PARKING BRAKE SYSTEM
ELECTRIC RETRACTABLE REMOTE CONTROLLED MIRROR
EMERGENCY STOP SIGNAL SYSTEM
ENGINE CONTROL SYSTEM
FORWARD COLLISION MITIGATION (FCM)
FRONT FOG LAMP
GLOVE BOX LAMP
HANDS-FREE INTERFACE SYSTEM
HEADLAMP LEVELLING SYSTEM
HEATED & POWER SEAT
IMMOBILIZER SYSTEM
JOINT CONNECTOR (JC)
METER AND GAUGE
MITSUBISHI MULTI COMMUNICATION SYSTEM (MMCS)
MITSUBISHI MULTI ENTERTAINMENT SYSTEM (MMES)
OFF-ROAD TRACTION CONTROL
ONE-TOUCH START SYSTEM
POWER DISTRIBUTION SYSTEM
RADIO AND CD PLAYER
REAR WINDOW WIPER AND WASHER
SHIFT LOCK MECHANISM
SMARTPHONE LINK DISPLAY AUDIO
STARTING SYSTEM
SUPER SELECT 4WD SYSTEM
FRONT AUTOMATIC AIR CONDITIONER AND REAR COOLER
TURN-SIGNAL LAMP AND HAZARD WARNING LAMP
SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
WINDSHIELD WIPER AND WASHER
AND MANY MORE

2. Configuration Diagrams Included:

DOOR
ENGINE
ENGINE COMPARTMENT
FLOOR
INSTRUMENT PANEL
OVERALL CONFIGURATION DIAGRAM
ROOF
TAILGATE
TRANSMISSION

3. Component Location Contents:

EARTH
FUSIBLE LINK AND FUSE
SPARE CONNECTOR,
EARTH CABLE
INSPECTION CONNECTOR
SPARE CONNECTOR

Additional Manuals:

4. General Vehicle Information
5. User Manual
6. Audio User Manual
7. Connect User Manual

Please Note:

All documents are received on a DVD in Adobe PDF format.
Kindly contact our friendly team for all queries.
