Shelly Wave Shutter (Z-wave)
Introducing the Wave Shutter, a revolutionary Z-Wave(R) controller equipped with power measurement capabilities, offering precise control over roller shutters, blinds, windows, awnings, pool covers, and more. With a remarkable 10 A per channel capacity, this device empowers you to automate and remotely manage the position of various motor-powered devices with ease.
Key Features:
- Control the tilt position (angle) of venetian blind slats for optimal light control
- Integrated power metering functionality for accurate energy consumption monitoring
- Ultra-low power consumption of less than 0.3 W
- Operates on the Z-Wave 800 Series technology for enhanced reliability
- Supports automatic setup with SmartStart and Security 2 Authentication for maximum security
- Enables over-the-air firmware updates for continuous improvement
- Compatible with Z-Wave-certified gateways and a wide range of Z-Wave devices
Installation and Compatibility: The Wave Shutter is designed for effortless retrofitting behind switches or push-buttons, instantly transforming them into smart devices. Once installed, simply integrate the device into your Z-Wave network via a compatible gateway, enabling seamless control of connected appliances from anywhere using your smartphone or tablet.
Functionalities:
- Effortlessly include the Wave Shutter into your Z-Wave network for remote control compatibility with all certified Z-Wave gateways
- Precisely set the desired position of blinds, roller shutters, screens, awnings, and more powered by bi-directional AC motors
- Adjust the tilt position (angle) of venetian blind slats to regulate the amount of natural light entering a room
- Establish direct communication between devices in your Z-Wave local network and configure custom actions without the need for a hub
- Create personalized schedules aligned with your daily routine or synchronized with sunrise/sunset for automated operation (gateway required)
- Design custom scenes by combining the Wave Shutter with other Z-Wave devices to enhance convenience and efficiency (gateway required)
Use Cases:
- Optimize your daily routines by programming Wave Shutter to open and close curtains at specific times, creating an ideal ambiance for starting and ending your day
- Enhance comfort while working from home by adjusting the position of venetian blinds and controlling the angle of blind slats to regulate natural light levels without interrupting your workflow
- Boost home security by integrating Wave Shutter with other devices to establish automated "Vacation Scenes" that simulate occupancy, deterring potential intruders while you're away
- Ensure the safety of your home by creating associations between Wave Shutter and Z-Wave weather sensors, enabling automatic adjustment of awnings in response to adverse weather conditions
Experience the unparalleled convenience, efficiency, and versatility of the Wave Shutter Z-Wave controller, designed to elevate your smart home experience and meet your unique needs effortlessly.
Specifications
| Power supply |
110-240 V AC 10% |
| Power consumption |
< 0.3 W |
| Power measurement [W] |
Yes |
| Max switching voltage AC |
240 V |
| Max switching current AC |
10 A per channel |
| Overheating protection |
Yes |
| Overcurrent protection |
Yes |
| Distance |
up to 40 m indoors (131 ft.)(depends on local condition) |
| Z-Wave repeater: |
Yes |
| CPU |
Z-Wave S800 |
| Z-Wave frequencies band(s) |
919,8 MHz (Australia & New Zealand) |
| Maximum radio frequency power transmitted in frequency bend(s) |
< 25 mW |
| Size (H x W x D) |
37 mm x 42 mm x 16 mm 0.5 mm / 1.46 in x 1.65 in x 0.63 in 0.02 in |
| Weight |
29 g / 1.02 oz. |
| Mounting |
Wall console |
| Screw terminals max torque |
0.4 Nm / 3.5 lbin |
| Conductor cross section |
0.5 to 1.5 mm? / 20 to 16 AWG |
| Conductor stripped length |
5 to 6 mm / 0.20 to 0.24 in |
| Shell material |
Plastic |
| Color |
Black |
| Ambient temperature |
-20oC to 40oC / -5oF to 105oF |
| Humidity |
30% to 70% RH |
| Max. altitude |
2000 m / 6562 ft. |
Compatibility with gateways
