Redarc 24v Smart Battery Isolator 200A Max C/Rate 600A In-Rush

Off Volts: 25.4 Volts. On Volts: 26.4 Volts.

Maximum Inrush Rating: 600amps.

Microprocessor-controlled Battery Isolator designed for use in multi-battery applications as a solenoid priority system to protect the start battery from excessive discharge whilst allowing the auxiliary battery to supply non essential loads. Ensures a low charge in the secondary battery won't drain the primary battery.

Silver Contacts- Cooler operating temperature- engaged draws 0.15amps- Fault indication- Red LED Light for solenoid activation- fully surge protected.

Applications: Extremely Heavy Duty operations- as found in Industrial and Mining situations.

Approximate Weight: 600g.

2 year Warranty

Off Volts: 25.4 Volts. On Volts: 26.4 Volts.

Maximum Inrush Rating: 600amps.

Microprocessor-controlled Battery Isolator designed for use in multi-battery applications as a solenoid priority system to protect the start battery from excessive discharge whilst allowing the auxiliary battery to supply non essential loads. Ensures a low charge in the secondary battery won't drain the primary battery.

Silver Contacts- Cooler operating temperature- engaged draws 0.15amps- Fault indication- Red LED Light for solenoid activation- fully surge protected.

Applications: Extremely Heavy Duty operations- as found in Industrial and Mining situations.

Approximate Weight: 600g.

2 year Warranty

The REDARC Smart Start SBI224 200A is a 24V DC 200A microprocessor-controlled, dual battery isolator designed

to protect the start battery from excessive discharge while allowing the auxiliary battery to supply charge to non-essential loads.
