QNAP TVS-h674-i5-32G Business High End Tower 6-Bay NAS Server, 6x 3.5" Bay, 2x [TVS-h674-i5-32G]
3x

QNAP TVS-h674-i5-32G Business High End Tower 6-Bay NAS Server, 6x 3.5" Bay, 2x [TVS-h674-i5-32G]

1 Review 5 1 Review
SOLD OUT

QNAP TVS-h674-i5-32G Business High End Tower 6-Bay NAS Server, 6x 3.5" Bay, 2x M.2 Slot, Intel i5-12400 6Core/12Thread Upto4.4 GHz, 32GB Memory (64GB Max), 2x2.5GbE,, 2x PCIe, 2x USB 3.2, 1xType C, HDMI, Come with 8 Camera License

QNAP TVS-H674-I5-32G External HDD/SDD Overview
With an Intel Core i5 6-Core-Core processor to support the ZFS-based QuTS hero operating system, the TVS-h674 6-Bay NAS Enclosure from QNAP ensures data integrity and supports block-level inline data deduplication and compression, near-limitless snapshots, real-time SnapSync, and SSD optimization. Whether for mission-critical file servers, virtualization servers, collaborative video editing, or efficient data backup and recovery applications, the TVS-h674 delivers an ideal NAS solution. The high-performance TVS-h674 provides PCIe Gen 4 (up to twice the transmission speed of Gen 3) expandability, M.2 NVMe SSD caching, and 2.5GbE connectivity for high-speed virtualization network environments.
This unit has six SATA III 6 Gb/s drive bays, all of which natively support 3.5" hard drives, as well as 2.5" hard drives and SSDs. Should users need to expand the overall capacity of their TVS-h674, optional expansion units may be connected. Also featured are two USB-A 3.2 Gen 2 ports and one USB-C 3.2 Gen 2 port, which allow it to be connected to external peripherals. You can also output video to an external display using the HDMI 1.4b port. Network connectivity is achieved via the two 2.5 Gigabit Ethernet ports with port trunking failover support, which helps to provide redundancy in the case that a LAN connection malfunction occurs on one port.
The TVS-h674 runs on either the QuTS hero 5.0.0 or QTS 5.0.1 operating system. Supported RAID modes include RAID 0, 1, 5, 6, 10, 50, and 60, each of which provides redundancy, performance, or a combination of both. For those who do not require a RAID, JBOD and Single are also available, allowing each drive bay to be individually utilized.
QNAP has engineered the TVS-h674 to be energy efficient. Not only does it offer dual 92mm system fans and a 60mm CPU fan, the server supports numerous scheduled power on / off cycles and hard-drive hibernation to further minimize power consumption and operation expenses. The TVS-h674 operates using an internal 250W power supply and includes an Ethernet cable, a power cord, 24 flat head screws for 3.5" HDDs, 18 flat head screws for 2.5" HDDs, two M.2 SSD heatsinks, and two drive tray keys. Protection is provided by a limited 3-year hardware warranty.
High-Performance Intel Core Processor Bursts up to 4.4 GHz
The TVS-h674 adopts a 2.5 GHz Intel Core i5-12400 6-Core Processor with Intel UHD Graphics 770 to increase multi-tasking capabilities, offering SMBs a secure, reliable, and high-performance NAS solution.
Boost NAS performance with M.2 SSDs or TPU
The TVS-h674 has two M.2 PCIe slots, enabling SSD caching or SSD storage pools for improved performance, or other applications.
Install M.2 NVMe SSDs for Cache Acceleration
The TVS-h674 supports SSD caching and features two M.2 slots that support M.2 PCIe NVMe SSDs with a 2280 form factor (sold separately) for boosting overall NAS performance.
Accelerate AI-Powered Image Recognition with TPU
By leveraging a Google Edge TPU to QNAP AI Core (AI-powered engine for image recognition), the TVS-h674 can perform high-speed face and object recognition. Google Edge TPU enables QuMagie to quickly process thousands of photos with high-speed AI Image recognition and classification, and QVR Face to analyze real-time video for instant facial recognition.
Note: Purchase this item from Coral website
Build a High-Speed 2.5GbE Network Environment
The TVS-h674 has two 2.5GbE ports. QNAP offers comprehensive, budget-friendly storage and networking solutions that provide an array of connectivity possibilities. Easily and flexibly upgrade your workplace or home network now to handle bandwidth-hungry applications.
A Fast 2.5GbE/10GbE NAS
A QNAP NAS featuring two or more 2.5GbE/10GbE ports and Port Trunking allows you to combine multiple ports for greater bandwidth potential.
Upgrade Computers and Servers
Servers and desktops can install PCIe-based QNAP network cards that support 10G/5G/2.5G/1G/100M Multi-Gig.
Add a 5GbE Port to Laptops
Laptops and upgrade-limited computers can use QNAP's portable USB 3.2 Gen 1 to 5GbE adapter that allows you to connect to 5G/2.5G/1G/100M networks via USB.
A Switch that Supports 2.5GbE+
QNAP's 10GbE/NBASE-T switches support 10G/5G/2.5G/1G/100M and allow connecting multiple workstations and devices for high-speed collaboration in device-dense environments.
Abundant I/O Capabilities with PCIe Expansion
The TVS-h674 has one PCIe 4.0 x16 slot and one PCIe 4.0 x4 slot that allow for installing various expansion cards for expanding application potential.
2.5/5/10GbE Network Card
Enable lightning-fast throughput for bandwidth-demanding tasks (virtualization, massive data transmission, and fast backup/restore).
QM2 Card
Add M.2 SSD caching, Edge TPU, or 2.5GbE/10GbE network connectivity to the NAS to optimize performance and bandwidth.
Graphics Cards
Supercharge your video editing and transcoding or enable GPU passthrough to virtual machines. Graphics cards are supported that can be powered solely through the PCIe slot with dimensions up to 6.7 x 1.9 x 4.4".
Ultimate Visual Experience with Full HD HDMI Output and Real Time Video Transcoding
HDMI Output
The TVS-h674 features an HDMI output that supports Full HD, providing great benefits for applications like video production/editing or industrial design that demand high resolution and intensive media storage, transfer, and display.
View NAS Media or Virtual Machines On a TV
By connecting the TVS-h674 to an HDMI display, you can directly watch multimedia content saved on the NAS, operate virtual machines from Virtualization Station, or enjoy multimedia using HD Player or third-party players like Plex Home Theater.
Real Time Transcoding and Display
The TVS-h674 features Intel UHD Graphics that supports hardware decoding and real-time transcoding for converting videos to universal file formats that can be smoothly played on multiple devices.
Note: The TVS-h674 provides hardware decoding, encoding, and transcoding capabilities. However, playback quality may vary due to factors, including playback software, file formats, system usage, and available bandwidth.
Faster Image Identification with Integrated Intel OpenVINO AI Engine
With integrated Intel OpenVINO AI computing resources, the TVS-h674 accelerates AI image recognition performance without impacting other applications or services. QNAP AI Core primarily works with the QuMagie application.
QuMagie Photo Management
Easy-to-use photo management solution that integrates AI image recognition and intelligent classification for your collection.
ZFS-Based QuTS hero Operating System Enhances NAS Performance and Data Integrity
QuTS hero combines the app-based QTS with the 128-bit ZFS file system to provide flexible storage management, comprehensive data protection, and optimized performance to tackle the complexity and performance demands of modern IT. From storage management and virtualization to collaborative media workflows, QuTS hero streamlines your business-critical tasks.
Data Integrity Is Key
QuTS hero's self-healing ensures data integrity and reliability. Write Once, Read Many (WORM) is also supported.
Data Reduction Improves Storage Efficiency and Performance
Inline data deduplication, compression, and compaction reduce file sizes to conserve storage capacity and optimize performance.
Multi-Level Cache Technology
Main memory read cache (L1 ARC), SSD second-level read cache (L2 ARC), and ZFS Intent Log (ZIL) for synchronous transactions with power failure protection are supported to boost performance and security.
RAID Z Enables Robust Data Protection
Multiple RAID levels allow flexible capacity utilization. RAID Triple Parity and Triple Mirror deliver higher levels of data protection.
QSAL (QNAP SSD Antiwear Leveling) Enhances Data Protection
RAID-level SSD lifespan is automatically and regularly detected to prevent simultaneous SSD failure, improving your data protection and system reliability.
App Center Ecosystem Extends NAS Functionality
Apps for backup/sync, virtual machines/containers, content management, productivity, and more features can be used to expand the application potential of the NAS.
Inline Data Deduplication, Compression, and Compaction Improve SSD Endurance
QuTS hero supports advanced block-based data reduction technologies (including inline data deduplication, compression, and compaction) to reduce file sizes, conserve storage capacity, and optimize performance. For example, if 20 virtual machines on a NAS are replicated using the same template, then storage space requirements for all 20 virtual machines can be reduced by up to 95%. Whether acting as primary or backup storage, the TVS-h674 optimizes storage utilization to provide a reliable storage cornerstone in the Big Data era. All-flash solutions thus achieve higher cost efficiency while improving both random write performance and SSD lifespan.
Note: Inline Data Deduplication requires a NAS with at least 16GB memory (at least 32GB memory is recommended for optimal performance).
Comprehensive Backup and Disaster Recovery Solution
The TVS-h674 supports various apps that cover all your backup needs. Practice safe IT habits by regularly backing up files and device content, allowing them to be easily restored when needed.
PC/Laptop Backup
For Windows, install NetBak Replicator to back up your PC to QNAP NAS. In macOS, just set up the built-in Time Machine to secure your data.
Remote Backup for NAS
Hybrid Backup Sync makes it easy to back up data from a TVS-h674 to another QNAP NAS or remote server to fulfill your 3-2-1 backup strategy.
VM Backup
Enjoy license-free VMware and Hyper-V VM backup with source-side incremental backup, global deduplication, and recovery compression.
Saas Backup
Safeguard enterprise cloud data by backing up/syncing files, emails, calendars, and contacts from Google Workspace and Microsoft Office 365 to the NAS.
Note: Minimum memory requirements are 2GB available and 4GB installed.
Cloud Backup for NAS
Hybrid Backup Sync supports mainstream cloud storage for NAS data backup. For backup to object cloud storage, VJBOD Cloud is especially useful to reduce bandwidth usage and backup time.
QuDedup Technology
Hybrid Backup Sync eliminates redundant data at the source and then backs up the deduplicated data, helping to save time and storage costs while providing efficient multi-version backups.
Real-Time Sync
Real-time SnapSync immediately synchronizes data changes with the destination storage, ensuring the primary and secondary NAS always have the same data. RPO is minimal to achieve real-time disaster recovery.
Note: SnapSync is supported by QNAP NAS models featuring the QuTS hero (4.5.3 or later) and QES (v2.1.1 or later) operating systems. These NAS can be paired with each other to provide a reliable backup storage solution.
Multi-Version Snapshots Mitigate Ransomware Threats
The TVS-h674 supports block-based snapshots that record the state of the system at any time. It helps protect data, which can be restored back to a specific point of time, greatly helping in mitigating the threat of ransomware.
Up to 65,536 Snapshots
QuTS hero supports enough snapshots for you to create one snapshot every hour for 7 years without needing to delete any. Copy-on-write technology makes snapshot creation almost instantaneous without affecting ongoing data writing.
Back Up Snapshots
Multiply data protection by backing up snapshot files. Replicate volume/LUN snapshots in the TVS-h674 to a remote NAS (Snapshot Replica) by copying only the changes made. This helps save time & bandwidth, and can be run manually or on a scheduled basis.
All-in-One Solution for Hosting Virtual Machines and Containers
By running multiple virtual machines and containers on the TVS-h674, you can deploy multi-tenant environments and applications to increase management efficiency and save hardware costs. Coupled with the Network & Virtual Switch app that boosts interoperability between virtual machines, containers, QNAP NAS, and other physical devices on the network, you can flexibly allocate physical and virtual network resources to simplify network deployment.
Virtualization Station
Run multiple Windows, Linux, UNIX, Android, and QuTScloud virtual machines and access them via a web browser or Virtual Network Computing (VNC). Businesses can run virtualized server applications on a single NAS without needing additional physical servers.
Container Station
Experience Docker, LXD, and Kata Containers lightweight virtualization technologies, download apps from the built-in Docker Hub Registry, import/export containers, and create abundant microservices.
Linux Station
Run Linux applications (including apps from the Software Center) directly on the NAS and remotely access the Linux desktop from a web browser. The open-source Linux platform is also ideal for Internet of Things development.
Comprehensive Security and Privilege Settings
The TVS-h674 is loaded with flexible privilege settings and security measures. Besides IP blocking, 2-step verification, and HTTPS connection, there are more apps that help ensure optimal NAS protection against threats like malware and hackers.
myQNAPcloud Secures Remote Access
myQNAPcloud allows convenient connection to the TVS-h674 through the internet without any complex DDNS settings. To ensure your remote access service is secure, myQNAPcloud strengthens keys on SSL Certificates to 2048-bits.
Simplified Privilege Settings
The TVS-h674 supports comprehensive access right settings for shared folders, Azure Active Directory Domain Services (Azure AD DS), LDAP, and Windows ACL to help IT staff efficiently manage user accounts and access rights for multiple NAS systems.
QuFirewall Protection
Supports IPv6, firewall access lists, and GeoIP filtering to restrict access based on geographical locations for higher NAS network security.
Superior Security with QVPN
A virtual private network (VPN) allows secure access to network resources and services across public networks
- MPN: TVS-h674-i5-32G
GTIN: 885022024735
