Powertran 12-30V / 240V 100VA EI Core Transformer

Powertran 12-30V / 240V 100VA EI Core Transformer

Price	$64.90
	Collect 192 Everyday Rewards points Score 3x points on every order Ends 11:59pm 16/02/2025. Exclusions & T&Cs apply Log in to MyDeal to link your card
Shipping	Free Shipping
	See delivery details

Quantity

Add to wishlist

Powertran EI-Core 240V AC mains transformer with 6A dual multi tapped secondary configuration. Two sets of 0V, 12V and 15V secondaries are available at a maximum current of 6A (max current when secondaries connected in parallel) . Primary is fitted with 200mm flyleads. Secondary taps have solder tags. Fully electrical authority approved for AS/NZS 61558.2.6.

Secondary Voltages Available:
Voltage : 12V Current : 6A*
Voltage : 15V Current : 6A*
Voltage : 24V Current : 3A
Voltage : 27V Current : 3A
Voltage : 30V Current : 3A
*Max Current when connected in parallel
Note: Must be used with a standard 500mA external fuse.

Specifications

Primary Voltage: 240V AC
Total VA Rating: 100VA
Insulation: Class E (120°C)
Magnetising Current: <85mA
Temperature Rise: <70°C
Regulation: ˜14%
Recommended primary AC Fuse: 500mA
Weight: ˜1.6kg
Primary connection: 200mm fly leads
Secondary connection: Solder tags
AS/NZS 61558.2.6 approval: Q042028
AS3108 approval: CS/813/Q

GTIN: 9321758250181
