Matelec FKW-15120-NMI - 3 Phase 100Amp KW Hour Meter - NMI Approved

What is a kilowatt hour watt?
kWh meters are compact electronic monitoring devices that measure the consumed energy flowing through a circuit such as a standard 240Vac line and act as a kWh calculator.

Product Features

• Accuracy Class: 1
• LCD Display
• 3 Phase
• Maximum Rated Current: 100A
• Nominal Voltage: 230/400Vac (3~)
• Operational Current Range: 0.25A - 100A
• Over Current Withstand: 1000A for 0.01s
• Operational Frequency Range: 50-60Hz
• Internal Power Consumption: <2W / 10VA per phase
• Test Output Flash Rate: 1000 impulses per kWh
• Power Supply Indicator: Mains power ON
• Consumption Indicator: Flashing on load
• Maximum Cable Capacity: 25mm² (Neutral 4mm²)
• Operating Temperature: -20º C - +55º C
• Operating Humidity: < 95%
• International Standard: IEC62052-11, IEC62053-21
• Warranty: 1 year
• Backup Battery: 3.6V Lithium
• Housing Material: Fire Resistant ABS
• Weatherproof Rating: IP51
• Tamper Proof: Kit available
• DIMENSIONS
• 100mm (H) x 122mm (W) x 65mm (D) 7 Module
