Manson 1-30V 30A DC Power Supply Switchmode Bench Top is designed with a highly efficient active power factor corrector. The constant current limiting protection allows the output current to remain stable but the output voltage decreases to a level that permits safe operation of the power supply.
The remote sensing terminals are used to compensate for output line losses 80 that a precise regulation can be achieved for critical voltage application away from the power supply.
The output voltage level and ON-OFF can be externally controlled via the remote terminal.
It is ideal for applications that need a good quality high DC current network with a precise point of voltage regulation.
SPS-9602 has a small footprint for its 900W continuous maximum power.
It is suitable for a wide range of applications such as street blaster super high power car audio demonstration console, radio equipment and etc.
Features:
Total max. continuous output current 30A
Main Output/Remote Sensing/ Remote Control/ terminalsat the back
Front terminals 3A limiting.
( Precise Load Point Voltage )
Remote Sensing for remote point of regulation.
Remote control terminals for output voltage adjustment and*on/off"
29HR Count Down Timer (Optional) for Output ON/OFF
Floating Ground Design
Overload / Over-temperature / Short Circuit Protections
Constant Current mode with LED indicator prevents overloading
Variable speed thermally controlled fan
High RFI stability
Active power factor correction ( P.E >0.97 )
AU/NZ Plug
Variable Output Voltage: 1- 30Vdc
Total Rated Output Current (Main Output + Front Output):Â 30A
Rated Output Current (Main Output):Â 30A
Rated Output Current (Front Output):Â 3A
Load Regulation (Main Output): 0.1%+5mV
Line Regulation (Main Output): 0.05% +3mV
Ripple & Noise (Peak-Peak): 50mVp-p
Input Voltage: 230Vac , 50Hz- ( or on request)
Efficiency: >85%
Meter Type: LED Meter
Voltmeter Range: 3 digit display
Ammeter Range: 3 digit display
Meter's Accuracy: ±I% +1 count
Protection Devices: Overload (Constant Current Limiting), Over Temperature, Short Circuit,
OVP protections
Cooling System: Variable speed thermally controlled fan
Special Feature: Remote sensing, Remote output voltage control and *on/off*
Approvals CE EMC : EN 55022 , LVD : EN 60950
Dimensions: 22 x 11 x 36Â cm (WxHxD)
Weight: 5.8kgs
Remarks: Power factor correction >0.95 at optimal load
This item comes with a 12-month warranty.
Please allow 2-8 business days for delivery.
