This series of 100W Switching Mode Power Supplies with Current Limiting Control is designed with the objectives of high accuracy, compactness and easy portability.
4 digit display LCD of voltage and current for high precision. The slim tower housing makes it ideal for a tight workbench. It is light and conveniently portable and a collapsible handle. The large and illuminated LCD display provides clear and sharp readings even under dim light. The output power on-off switch allows safe and handy operations. The Tracking OVP (output over-voltage protection) ensures better and tighter protection to voltage sensitive loads. It has good line and load regulations, high efficiency and low ripple and noise that are typical of advanced switching mode power supply.
Manson 1-20VDC 5A Slim Multi-Voltage Switchmode Power Supply LCD meets the CE safety standards EN-61010 for laboratory grade power supply and respective EMC standards.
Features:
Automatic Cross over CV and CC mode
Illuminated LCD indications of A, V, Output On-Off, CC and CV
4 digit displays of Volt and Amp meters
Voltage and Current Controls
Compact slim tower housingCollapsible handle
Output power on-off switch at the front panel
Natural Convection
Tracking OVP(output over-voltage protection), ShortCircuit, overload and over temperature protections
Good line, load regulations and low ripple and noise
Rotary encoder control
CE approvals
Specifications
Colour: White
Input Voltage...200-240VAC, 50/60Hz~(or on request)
Full Load Input Current at 230VAC...0.83A
Output Voltage Adjustable Range...1-20VDC
Output Current Adjustable Range...0-5A
Voltage Regulation
Load from 10% to 100% Variation...50mV
Line from 180 to 264VAC Variation...20mV
Ripple and Noise in r.m.s....5mV
Ripple and Noise (peak to peak)...30mV
Current Regulation
Load from 10% to 100% Variation...20mA
Line from 180 to 264VAC Variation...20mA
Ripple and Noise (peak to peak)...20mA
Switching Operation Frequency...80KHz to 120KHz
Power Factor...0.68
Efficiency at Maximum Power...84%
Display...4 Digit
Volt. Meter Accuracy...±1% +5 counts for range V =5V
.....................................±1% +3 counts for range V >5V
Curr. Meter Accuracy...±1% +5 counts for range V =2A
.....................................±1% +3 counts for range V >2A
LCD Indication...C.C., C.V. , Amp, Volt, output on/off
Protection...Short Circuit, Overload, Over Tempertature, Tracking OVP
Approvals...CE EMC:EN55011 LVD:EN61010
Cooling System...Natural Convection
Dimensions (WxHxD) 70x150x250mm 2.8x6x9 inch
Weight...Approx 2kgs 4.4lbs
This item comes with a 12-month warranty.
