Manson 1-16V 0-30A Power Supply Switching 3 Digi LED w/ USB is ideal for laboratory, university, workshop, production, quality control and advanced DIY.
Computer interface via USB for cyclical operation, plus wired analogue remote control make these power supplies open up many demanding applications.
Fine and Coarse tuning with definitive rotary encoder volume knob and open circuit CC setting is really user friendly.
This range of high graded SMPS is designed for a wide range of applications for telecommunications, laboratory and industry. The power-efficient circuit designs allow units to have small form factor with low profile and small footprint casings. The intelligent fan speed control program checks the fan at power on and adapts the right speed to ensure a quiet and safe operation of the power supply at different ambient temperatures and power output levels. The dual action (coarse & fine set) control knobs make tuning the voltage and current level ever so smooth, precise and fast, due to the rotary encoder and microprocessor control. Setting the CC current limiting can be done in open circuit at output poles. The isolated ground construction allows parallel and series connection of power supplies with ease and safety. The three user-defined presets of voltage and current limiting levels facilitate quick access to frequently used VI settings. Analogue remote control functionality offer a wide range of operation possibilities for industrial and more sophisticated users. We add a USB port for access to a computer to run cyclical operation with programmable voltage, current, period time and cycles.
Features:
Rotary Encoder Control Knob with coarse & fine-tuning
PC interface USB for program runs of up to 20 sets V I, time set, and 999 cycles.
Wired analogue remote controls of on-off, V, and I
High RFI immunity & excellent EMI
Intelligent fan control from zero to full speed
3 user presets on unit
Open circuit Constant current limit
Isolated ground and active PFC & high power efficiency
Overload, Over Temperature & Tracking Over Voltage protections
Remote Programmable via USB to computer
Application software, command sets and Labview driver.
Output Voltage: 1-16V
Output Current: 0-30A
Colour: Black
Dimensions Approx.: 20 x 21.5 x 9 cm (WxDxH)
Weight Approx.: 2.6 kg
Variable Output Voltage: 1-16VDC
Variable Output Current: 0-30A
Load (10-100% Load): ≤50mV
Line (170-264VAC Variation): ≤20mV
Load(10-90% Rated Voltage): ≤150mA
Line(170-264VAC Variation: ≤50mA
Ripple & Noise (r.m.s) Voltage: ≤5mV
Ripple & Noise (peak-peak) Voltage: ≤50mV
Switching Frequency: 65-58KHz~
Tracking Over Voltage Protections: O/P 1-5V: set voltage +2V, O/P 5-16V: set voltage +3V
Voltage Meter: 3 Digit LED Display ±(0.2% + 3counts)
Current Meter: 3 Digit LED Display ±(0.2%+3counts)
Input Voltage: 200-240VAC 50-60Hz ~(or on request)
Full Load Input Current: 2.4A
Efficiency: ≥85.5%
Power Factor Control: Power factor correction >0.95 at optimal load
Cooling Method: Thermostatic Control Fan from Zero to full speed
Protections: Overload, Short Circuit by Constant Current, Output Tracking Over Voltage, Over Temperature
Special Features: 3 User-defined V & I preset, Analogue Remote control V, I and output on-off
Preset Cycle Programming: Max. 20 presets of V&I; Max. preset cycle 999
Approvals: CE EMC: EN 55011, 55022 LVD: EN 60950, 61010
