Lowara 6” Submersible Borehole Pump Z Series 415 V 3 Phase 50Hz 2 Year Warranty

Lowara multi-stage centrifugal submersible pumps for clean water in 6 wells. Made of AISI 304 or AISI 316 stainless steel.

These durable and lightweight pumps assure high-efficiency, low maintenance costs and ease of management. Their main characteristics include the possibility of replacing the impeller inlet wear ring. Available in the high-pressure version to guarantee heads of up to 700 metres. Can be coupled to all NEMA standard motors.

• For 150mm nominal bore and larger diameter Wells
• Motor sizes up to 5.5kW (4) 95mm diameter; Hitachi 5.5kW and larger (6) 140mm diameter
• Price includes individual 4m motor leads, splice kit and bolts
• 4Z denotes 4 motor, 5m flat jacketed lead
• 6 motors have a 0 metre lead
• Higher head models available, POA
• 2 year warranty on Z series submersibles

Please Note: Bolts and spring washers supplied with complete pump set only.

Specifications:

• Delivery: up to 78 m3/h
• Head: up to 700 metres (high-pressure version)
• Power supply: three-phase 50 and 60 Hz
• Three-phase version: 380-415 V
• Power: 0.55 kW to 55 kW
• Can be coupled with L4C, L6W and L8W three-phase asynchronous motors in a coolant bath.
• Maximum overall diameter of pump (two cable covers included):
  • 144 mm (standard version),
  • 195 mm (high-pressure version)
• Water temperature: 0°C to +60°C (depending on the limits of the associated motor)
• Maximum permissible quantity of suspended sand: 100 g/m³

Applications:

• Water supply
• Pressure boosting
• Irrigation
• Fire-fighting
• Mining industry
• Golf
• Groundwater level control

Materials:

• Delivery port, non-return valve, diffuser, impeller, cable cover, lower support, pump shaft, coupling, spacer, screws, tie-rods: Stainless steel
• Thrust bearing: PTFE
• Wear ring: Technopolymer PPO
• Upper bearing: tungsten carbide
• Shaft guide bearing: polyurethane
• Elastomers: EPDM

Market Sectors:

• Light Industrial
• Agriculture
• Municipal

Models:

• Z6, ZN6

The product image shown is for illustration purpose only
