Intel® Xeon® W-2223 Processor, 8.25M Cache, 3.60 GHz, 4 Core, 8 Thread, Boxed, 3 Year Warranty

Intel® Xeon® W-2223 Processor, 8.25M Cache, 3.60 GHz, 4 Core, 8 Thread, Boxed, 3 Year Warranty

CPU Specifications

• Total Cores 4
• Total Threads 8
• Max Turbo Frequency 3.90 GHz
• Processor Base Frequency 3.60 GHz
• Cache 8.25 MB
• Bus Speed 8 GT/s
• TDP 120 W

Memory Specifications

• Max Memory Size (dependent on memory type) 1 TB
• Memory Types DDR4 2666
• Max # of Memory Channels 4
• Max Memory Bandwidth 85.3 GB/s
• Physical Address Extensions 46-bit
• ECC Memory Supported ‡ Yes

Expansion Options

• Scalability 1S Only
• PCI Express Revision 3
• PCI Express Configurations ‡ x4 | x8 | x16
• Max # of PCI Express Lanes 48

Package Specifications

• Sockets Supported FCLGA2066
• Max CPU Configuration 1
• TCASE 64 Deg C
• Package Size 45mm x 52.5mm

Advanced Technologies

• Intel® Deep Learning Boost (Intel® DL Boost) Yes
• Intel® Optane™ Memory Supported ‡ No
• Intel® Speed Shift Technology Yes
• Intel® Turbo Boost Max Technology 3.0 ‡ No
• Intel® Turbo Boost Technology ‡ 2
• Intel® Hyper-Threading Technology ‡ Yes
• Intel® Transactional Synchronization Extensions Yes
• Intel® 64 ‡ Yes
• Instruction Set 64-bit
• Instruction Set Extensions Intel® SSE4.2 | Intel® AVX | Intel® AVX2 | Intel® AVX-512
• # of AVX-512 FMA Units 2
• Idle States Yes
• Enhanced Intel SpeedStep® Technology Yes
• Intel® Demand Based Switching Yes
• Thermal Monitoring Technologies Yes
• Intel® Identity Protection Technology ‡ Yes
• Intel® Volume Management Device (VMD) Yes

Security & Reliability

• Intel vPro® Eligibility ‡ Intel vPro® Platform
• Intel® AES New Instructions Yes
• Secure Key Yes
• Intel® Software Guard Extensions (Intel® SGX) No
• Intel® Memory Protection Extensions (Intel® MPX) Yes
• Intel® OS Guard Yes
• Intel® Trusted Execution Technology ‡ Yes
• Execute Disable Bit ‡ Yes
• Intel® Boot Guard Yes
• Intel® Virtualization Technology (VT-x) ‡ Yes
• Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
• Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
