Intel i7 14700K CPU

Intel i7 14700K CPU 4.3GHz (5.6GHz Turbo) 14th Gen LGA1700 20-Cores 28-Threads 33MB 125W UHD 770 Graphic Unlocked Retail Raptor Lake no Fan

• Total Cores 20
• # of Performance-cores 8
• # of Efficient-cores 12
• Total Threads 28
• Max Turbo Frequency 5.6 GHz
• Intel® Turbo Boost Max Technology 3.0 Frequency ‡ 5.6 GHz
• Performance-core Max Turbo Frequency 5.5 GHz
• Efficient-core Max Turbo Frequency 4.3 GHz
• Performance-core Base Frequency 3.4 GHz
• Efficient-core Base Frequency 2.5 GHz
• Cache 33 MB Intel® Smart Cache
• Total L2 Cache 28 MB
• Processor Base Power 125 W
• Maximum Turbo Power 253 W
• Max Memory Size (dependent on memory type) 192 GB
• Memory Types Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s
• Max # of Memory Channels 2
• Max Memory Bandwidth 89.6 GB/s
• ECC Memory Supported ‡ Yes
• Processor Graphics ‡ Intel® UHD Graphics 770
• Graphics Base Frequency 300 GHz
• Graphics Max Dynamic Frequency 1.6 GHz
• Graphics Output eDP 1.4b | DP 1.4a | HDMI 2.1
• Execution Units 32
• Max Resolution (HDMI)‡ 4096 x 2160 @ 60Hz
• Max Resolution (DP)‡ 7680 x 4320 @ 60Hz
• Max Resolution (eDP - Integrated Flat Panel)‡ 5120 x 3200 @ 120Hz
• DirectX* Support 12
• OpenGL* Support 4.5
• OpenCL* Support 3
• Multi-Format Codec Engines 2
• Intel® Quick Sync Video Yes
• Intel® Clear Video HD Technology Yes
• # of Displays Supported ‡ 4
• Device ID 0xA780
• Direct Media Interface (DMI) Revision 4
• Max # of DMI Lanes 8
• Scalability 1S Only
• PCI Express Revision 5.0 and 4.0
• PCI Express Configurations ‡ Up to 1x16+4 | 2x8+4
• Max # of PCI Express Lanes 20
