Thornado 3 Inch 7HP (212cc) Petrol Water Pump
A petrol water pump is a pump that uses gasoline as its power source to move water from one location to another. Petrol water pumps are available in a variety of sizes and designs, but they all work on the same basic principle. The suction created by centrifugal force draws water into the pump. Petrol water pumps are extremely versatile and can be used in a variety of applications. Petrol water pumps are commonly used in agricultural and construction applications where large volumes of water must be moved quickly. A petrol water pump can move water quickly and efficiently for irrigation, drainage, or any other purpose.
The THORNADO 3 inch water transfer pump not only increases the required power but also features a new design of the pump impeller and pump body thickness. The Thornado 7HP petrol engine powers the 3 inch water pump. With a suction/discharge diameter of 80mm (3 inches), this water pump has a maximum delivery lift of 30m and a maximum water displacement rate of 60,000 litres per hour. With the ability to draw water up to 7m in height, the Thornado 3 inch water pump will come in handy in a variety of situations.
Because of its small size, light weight, and portability, the Thornado 3 inch water transfer pump is highly efficient and has multiple applications. The Thornado 3 inch petrol water transfer pump appears to be the ideal solution for use in a variety of locations including flower nurseries and gardens, water plants, mines, factories, ships, and villages where water needs to be drained remotely.
Thornado 3 Inch Petrol Water Pump Key Features
- Powered by Thornado 7HP Petrol Engine
- EPA III certified engine - Reduce carbon footprint
- Max heads 30 metres
- Max flows 60,000 litres per hour
- Suction depth 7 metres
- 3 inch Suction/Discharge Ports
- Anti-vibration design
- High-quality mechanical seal
- Rigid Mounted Cast Iron Volute and Cast Iron Impeller
- Heavy Duty Full Frame Protection
- Low oil alert installed to prevent engine damage by automatically shutting the engine down when oil drop below the safe operating level
- 12 Months Warranty
Suitable Applications
- Water transfer from dam
- Tank filling
- Irrigation
- Sprinkler
- Washing
- Shallow Well
- Water Carts
- Fish Farm (Fresh Water)
- Crop spraying
| SPECIFICATIONS |
| Model No |
TH-WP30A |
| Type |
Self priming, Centrifugal pump |
| Inlet Size |
3 inch (80mm) |
| Outlet Size |
3 inch (80mm) |
| Max Lift Head |
30m |
| Max Flow |
60,000 litres/hour |
| Max Suction Depth |
7m |
| Max Pressure |
42 PSI |
| Material |
Alluminium alloy pump housing, cast iron impeller and diffuser |
| Engine |
TH-070QR (7HP) |
| Engine Type |
4 stroke, air cooled |
| Max Power HP / Rpm |
7HP / 3600 Rpm |
| Displacement |
212cc |
| Fuel Type |
Petrol |
| Oil Type |
SAE10w-30 / SAE30 |
| Fuel Tank Capacity |
3.6L |
| Oil Capacity |
0.6L |
| Run Time Full Tank |
2.6h at load |
| Starting System |
Recoil start |
| Product Length |
515mm |
| Product Width |
440mm |
| Product Height |
440mm |
| Product Weight |
26kg |
| In the Box |
Hose fittings, hose clamps, intake strainer, spark plug wrench, user manual, |
