Specifications | |
---|---|
Colour | Amber |
Type | LED |
Pattern | Rotating |
Voltage | Multivolt |
No. of LED | 8 |
Mount | 3 Bolt |
Width (mm) | 165 |
Height (mm) | 119 |
Specifications | |
---|---|
Colour | Amber |
Type | LED |
Pattern | Rotating |
Voltage | Multivolt |
No. of LED | 8 |
Mount | 3 Bolt |
Width (mm) | 165 |
Height (mm) | 119 |
Rotating Flash Pattern
Amber Illumination
8 x 1.25 Watt High Intensity Warm White LED's
Amber Optical PMMA Polycarbonate Lens - Twist On or Off
Orange durable ABS Plastic Housing
3 Bolt Mount
Fully encapsulated circuitry
0.8amps at 12 Volt and 0.4amps at 24 Volt Current Draw
10-000 Hours LED Lifespan
CISPR25 Power Controlled Class V RF Suppression Approved
IP5KX- IPX4K and IPX9K Rating
2 Year Warranty
Spare Parts:-
HMWGA160 GuardRay Protective Grille / Cage
Schematics:
1103468
1103468
