DT Swiss HX 1700 Spline 30 Tubeless Disc eMTB Wheel

DT Swiss HX 1700 Spline 30 Tubeless Disc eMTB Wheel

Limited Stock!

Price	From $599.99
	Collect 1797 Everyday Rewards points Score 3x points on every order Ends 11:59pm 03/12/2024. Exclusions & T&Cs apply Log in to MyDeal to link your card
Size	Please select an option
Shipping	$14.00 Australia-wide
	See delivery details

Quantity

Add to wishlist

A high-end aluminum wheelset with proven technology to extend your eMTB ride.

An eMTB is designed to quickly ride up and down mountains and to provide fun. The new HX 1700 SPLINE, the high-end aluminum wheelset, does precisely that. With several years of expertise in hybrid bicycle components and specific, demanding testing procedures, DT Swiss has redesigned this wheelset to suit the extended use of e-mountain biking. The redesigned 350 hub features a bigger hub body, enabling better brake and drive torque resistance, resulting in better durability. The new hub is now combined with a high-end welded aluminum rim and reinforced hybrid spokes. This wheel is available in two inner widths and two wheel sizes and therefore ready for anyone who wants to extend their eMTB adventure.

	REAR WHEEL	FRONT WHEEL	REAR WHEEL	FRONT WHEEL
GENERAL
NET WEIGHT	1139g	1005g	1086g	952g
RECOMMENDED SYSTEM WEIGHT MAX	150kg	150kg	150kg	150kg
ASTM CLASSIFICATION	2	2	2	2
RECOMMENDED FOR eBikes	Yes	Yes	Yes	Yes
RIM
MATERIAL	Aluminium	Aluminium	Aluminium	Aluminium
RIM JOIN	Welded	Welded	Welded	Welded
TYRE INTERFACE	Hooked / Crotchet tubeless TC	Hooked / Crotchet tubeless TC	Hooked / Crotchet tubeless TC	Hooked / Crotchet tubeless TC
VALVE HOLE	Presta	Presta	Presta	Presta
RIM DIAMETER	29"" / 700C	29"" / 700C	27.5"" / 650B	27.5"" / 650B
RIM HEIGHT	21mm	21mm	21mm	21mm
INNER WIDTH	30mm	30mm	30mm	30mm
OUTER WIDTH	35mm	35mm	35mm	35mm
HUB
HUB TYPE	350	350	350	350
AXLE SYSTEM	12 mm Thru Axle	12 mm Thru Axle	12 mm Thru Axle	12 mm Thru Axle
BUILT-IN DIMENTION	148mm Boost	110mm Boost	148mm Boost	110mm Boost
BRAKE INTERFACE	Disc IS (6 Bolt)	Disc IS (6 Bolt)	Disc IS (6 Bolt)	Disc IS (6 Bolt)
CASSETTE INTERFACE	Sram XD	-	Sram XD	-
FREEHUB BODY	SRAM XD Steel (SSRAM)	-	SRAM XD Steel (SSRAM)	-
FREEHUB SYSTEM	Ratchet System 24	-	Ratchet System 24	-
SPOKES & NIPPLES
SPOKES LEFT	DT hybrid 1 Straightpull	DT hybrid 1 Straightpull	DT hybrid 1 Straightpull	DT hybrid 1 Straightpull
SPOKES RIGHT	DT hybrid 1 Straightpull	DT hybrid 1 Straightpull	DT hybrid 1 Straightpull	DT hybrid 1 Straightpull
SPOKE PATTERN	Three-cross (1:1)	Three-cross (1:1)	Three-cross (1:1)	Three-cross (1:1)
NIPPLES	DT ProLock Squorx ProHead alu	DT ProLock Squorx ProHead alu	DT ProLock Squorx ProHead alu	DT ProLock Squorx ProHead alu
INCLUSIVE
	Tubeless tape 32 mm	Tubeless tape 32 mm	Tubeless tape 32 mm	Tubeless tape 32 mm
	Tubeless valve MTB 32 mm	Tubeless valve MTB 32 mm	Tubeless valve MTB 32 mm	Tubeless valve MTB 32 mm
