The D-Link DGS-1005A 5-Port Gigabit Desktop Switch provides a convenient way to share a home or small office network connection with four other devices.
Fast and Reliable Networking
The D-Link 5-Port Gigabit Unmanaged Desktop Switch creates a blazing-fast network for your office, as its Gigabit Ethernet ports, provide high-speed wired connections for up to five PCs or other devices. The DGS-1005A also features QoS, which prioritizes network traffic so that time-sensitive data is delivered efficiently, even during bursts of high data traffic.
Conserve Energy
The 5-Port Gigabit Unmanaged Desktop Switch helps you conserve energy automatically through several methods. It automatically powers down ports that have no link, allowing the switch to save a substantial amount of power by cutting power usage for unused ports or ports connected to computers that have been shut down.
Environmentally Friendly
The 5-Port Gigabit Unmanaged Desktop Switch was designed with the environment in mind and is compliant with Energy Star Level V, as well as with the stringent CEC and MEPS regulations that require the use of energy-efficient power adapters. The switch is also built to follow RoHS standards to minimize the use of hazardous materials and uses recyclable packaging that helps reduce waste, complying with the WEEE directive.
Specifications
1000Base-T Interface: 5
Auto MDI/MDIX: Yes
Switching Capacity: 10 Gbps
Max. Packet Forwarding Rate: 7.44 Mpps
Store & Forwarding Forwading: Yes
Dimension: 91 x 73 x 22 mm
Weight: 0.08 kgs
Operation Temperature: 0 ~ 40 °C
Storage Temperature: - 10 ~ 70 °C
Operation Humidity: 0% ~ 95% RH
Storage Humidity: 0% ~ 95% RH
Operating Altitude: 2000m
Maximum Power Consumption: 3.90 W
Standby Power Consumption: 0.6W
Maximum Heat Dissipation: 13.299 BTU/h
MTBF: 1,152,221 hours
Power Input: AC：100 ~ 240 V
Flash Memory Size: 64KBytes
Packet Buffer Size: 128KBytes
FAN: Fanless
Comply with RoHS 6: Yes
Energy Efficiency Ethernet (EEE): Yes
Power Saving By Link Status: Yes
Power Saving By Cable Length: Yes
MAC Address Table Size: 4K
802.3x Flow Control: Yes
Head-of-line (HOL) Blocking Prevention: Yes
Jumbo Frame: 9,720 Bytes
Surge/Lightning Protection (AC Power Inet): 1kV
Surge/Lightning Protection (All Ethernet Ports): 1kV
Air Discharge: 8kV
