Designed for office and data center applications, the Online (High-Density) adopts double-conversion topology to provide seamless Pure Sine Wave output.
The generator-compatible UPSs feature hot-swappable battery packs for maintenance without power interruption.
The products also adopt ECO Mode to save on energy costs, Battery Management Technology to help batteries obtain optimal lifespan, and color LCD Display to display key information at a glance.
The power management software allows users to easily control and monitor the UPS system.
Features:
Online (Double Conversion) UPS Topology
Energy Saving Technology
Generator Compatible
Critical/Non-critical Load Outlets
Zero Transfer Time
Battery Management Technology
Smart Battery Management (SBM)
Extended Battery Module (EBM)
Graphical LCD Display
PowerPanel® Management Software
SNMP/HTTP Remote Management Capability
Rack/Tower Convertible Configurations
Application:
SOHO Office
Office
Back Office
Server Room
Data Center
Supermarket
Factory
Airport
Train Station
Product Callouts:
Power On Indicator
Power On/Off Switch
LCD Display Panel
Function Button(s)
Battery Backup & Surge Protected Outlets
Output Circuit Breaker
AC Inlet
BM/ENV Port
Serial Port
USB Port
SNMP/HTTP Network Slot
Extended Battery Module Connector
EPO Port
Includes:
1x CP 6000VA/W Rack Tower UPS
General
UPS Topology: Online Double Conversion
Energy Saving Technology: Online ECO Mode Efficiency > 96%
Active PFC Compatibility: Yes
Input
Generator Compatibility: Yes
Nominal Input Voltage (Vac): 200 ± 2%, 208 ± 2%, 220 ± 2%, 230 ± 2%, 240 ± 2%
Input Voltage Range (Vac): 180 ~ 280
Input Frequency (Hz): 50 ± 10, 60 ± 10
Input Frequency Detection: Auto-sensing
Rated Input Current (A): 32
Input Power Factor: 0.99
Input Connector Type: Hardwire Terminal Block
Output
Capacity (VA): 6000
Capacity (Watts): 6000
On Battery Waveform: Pure Sine Wave
On Battery Voltage(s) (Vac): 200 ± 2%, 208 ± 2%, 220 ± 2%, 230 ± 2%, 240 ± 2%
Output Voltage Setting: Configurable
On Battery Frequency (Hz): 50 ± 0.5%, 60 ± 0.5%
Output Frequency Setting: Configurable
Power Factor: 1
Overload Protection: Internal Current Limiting, Circuit Breaker, Fuse
Overload Protection (Line Mode): 105~125% Load for 1 min, 125~150% Load for 10 sec
Overload Protection (Battery Mode): 105~130% Load for 10 sec, 130~150% Load for 2 sec
Overload Protection (Bypass Mode): Circuit Breaker
Harmonic Distortion (Linear Load): THD<3%
Harmonic Distortion (Non-linear Load): THD<5%
Outlet(s) - Total: 7
Outlet Type: IEC C19 x 2, IEC C13 x 4, Hardwire Terminal Block x 1
Outlet(s) - Battery & Surge Protected: 7
Outlet(s) - Critical Load (CL): 4
Outlet(s) - Non-Critical Load (NCL): 3
Typical Transfer Time (ms): 0
Battery
Runtime at Half Load (min): 4.9
Runtime at Full Load (min): 1.4
Typical Recharge Time (Hours): 4
Smart Battery Management (SBM): Yes
User-replaceable: Yes - Qualified Personnel Only
Hot-swappable: Yes
Battery Type: Sealed Lead-acid
Replacement Battery Pack: RBP0144
RBP Quantity (pcs): 1
Extended Battery Module (EBM): BPE144VL2U01 (Built-in Charger)
Max. EBM Quantity (pcs): 10
Surge Protection & Filtering
Surge Suppression (Joules): 2430
EMI/RFI Filtration: Yes
Management & Communications
LCD Panel: Yes
LCD Orientation: Automatic LCD screen orientation, Rotatable LCD panel
HID Compliant USB Port(s): 1
Serial Port: Combo (RS232 + Dry Contact)
Emergency Power Off (EPO) Port: Yes
Power Management Software: PowerPanel® Business
SNMP/HTTP Remote Monitoring: Yes – Pre-installed
Physical
Form Factor: Rack/Tower
Physical Size - UPS Module
Dimensions (WxHxD) (mm.): 433 x 86.5 x 720
Weight (kg.): 42
Installed Rack Height (U): 2
Environmental
Operating Temperature (°C): 0 ~ 40
Operating Relative Humidity (Non-condensing) (%): 0 ~ 90
Online Thermal Dissipation (BTU/hr): 1613
Certifications
Certifications: CE, EAC, RCM
RoHS: Yes
