APC Smart-UPS X 1000VA, 230V, LCD, rackmount/tower, 2U, 8x IEC 320 C13 & 2x IEC Jumpers outlets.
Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Auto recognition of external batteries: UPS recognizes when external battery packs are attached and automatically adjusts runtime.
Cold-start capable: Provides temporary battery power when the utility power is out.
Energy meter: Provides actual kilowatt hours of usage for energy conscious users.
EPO: Attach the device to an Emergency Power Off (EPO) system so that power can be turned off in an emergency situation.
Green mode: Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
High frequency design: Reduces or eliminates bulky transformers resulting in lighter units for ease of handling.
High online efficiency: Reduces utility costs, generates less heat.
Intelligent Card Slot: Customize UPS capabilities with management cards.
Intuitive LCD interface: Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
Multiple switched outlet groups: Multiple outlet groups that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
Plug-and-Play external batteries: Ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS.
Predictive replace battery date: Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
Pure sine wave output on battery: Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
Rack/Tower convertible: Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
Scalable runtime: Allows additional run time to be quickly added as needed.
Temperature-compensated battery charging: Prolongs battery life by regulating the charge voltage according to battery temperature.
Adaptability
Adjustable voltage-transfer points: Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Adjustable voltage sensitivity: Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Availability
Disconnected battery notification: Warns when a battery is not available to provide backup power.
Intelligent battery management: Maximizes battery performance, life, and reliability through intelligent, precision charging.
Automatic self-test: Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Boost and Trim Automatic Voltage Regulation (AVR): Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
Automatic restart of loads after UPS shutdown: Automatically starts up the connected equipment upon the return of utility power.
Power conditioning: Protects connected loads from surges, spikes, lightning, and other power disturbances.
Temperature-compensated battery charging: Prolongs battery life by regulating the charge voltage according to battery temperature.
Manageability
Audible Alarms: Provides notification of changing utility power and UPS conditions.
Serial connectivity: Provides management of the UPS via a serial port.
USB connectivity: Provides management of the UPS via a USB port (not available on all models).
LED status indicators: Quickly understand unit and power status with visual indicators.
Network manageable: Most models provide remote power management options of the UPS over the network. Many do not have NMC embedded.
Includes:
1x CD with Software
1x Documentation CD
1x Installation Guide
1x Rack Mounting Brackets
1x Removable Support Feet
1x Smart UPS Signalling RS-232 Cable
1x USB Cable
Output
Max Configurable Power (Watts): 800 Watts / 1.0kVA
Output Voltage Distortion: Less than 5 %
Output Frequency (sync to mains): 50/60 Hz +/- 3 Hz Sync to mains
Topology: Line interactive
Waveform type: Sine wave
Input
Input frequency: 50/60 Hz +/- 3 Hz Auto-sensing
Input voltage range for main operations: 151 - 302 Adjustable, 160 - 286V
Number of Power Cords: 1
Batteries & Runtime
Battery type: Lead-acid battery
Typical recharge time: 3hour(s)
Replacement Battery: APCRBC116
Expected Battery Life (years): 3 - 5
RBC Quantity: 1
Battery Charge Power (Watts): 99 Watts
DC Overcurrent Protection: 60A
Communications & Management
Interface Port(s): RJ-45 Serial, SmartSlot, USB
Control panel: Multifunction LCD status and control console
Audible Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Emergency Power Off (EPO): Yes
Available SmartSlotâ„¢ Interface Quantity: 1
Surge Protection and Filtering
Surge energy rating: 600Joules
Filtering: Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical
Maximum Height: 89MM, 8.9CM
Maximum Width: 432MM, 43.2CM
Maximum Depth: 490MM, 49.0CM
Net Weight: 22.86KG
Shipping weight: 27.32KG
Shipping Height: 246MM, 24.6CM
Shipping Width: 589MM, 58.9CM
Shipping Depth: 620MM, 62.0CM
Colour: Black
Units per Pallet: 8.0
Environmental
Operating Temperature: 0 - 45 °C
Operating Relative Humidity: 0 - 95 %
Operating Elevation: 0 - 3048meters
Storage Temperature: -15 - 45 °C
Storage Relative Humidity: 0 - 95 %
Storage Elevation: 0 - 15240meters
Audible noise at 1 meter from surface of unit: 40.0dBA
Online thermal dissipation: 82.0BTU/hr
