AMD Ryzen 7 7700

AMD Ryzen 7 7700 8 Cores / 16 Threads, 65 watts, Max Freq 5.3Ghz, 40MB Cache, Wraith Prism Cooler & Radeon Graphics

General Specifications

• Platform Desktop
• Market Segment Enthusiast Desktop
• Product Family AMD Ryzen™ Processors
• Product Line AMD Ryzen™ 7 Processors
• AMD PRO Technologies No
• Consumer Use Yes
• Regional Availability Global,
• Former Codename "Raphael AM5"
• Architecture "Zen 4"
• # of CPU Cores 8
• Multithreading (SMT) Yes
• # of Threads 16
• Max. Boost Clock Up to 5.3GHz
• Base Clock 3.8GHz
• L1 Cache 512KB
• L2 Cache 8MB
• L3 Cache 32MB
• Default TDP 65W
• Processor Technology for CPU Cores TSMC 5nm FinFET
• Processor Technology for I/O Die TSMC 6nm FinFET
• CPU Compute Die (CCD) Size 71mm²
• I/O Die (IOD) Size 122mm²
• Package Die Count 1
• Unlocked for Overclocking Yes
• AMD EXPO™ Memory Overclocking Technology Yes
• Precision Boost Overdrive: Yes
• Curve Optimizer Voltage Offsets: Yes
• AMD Ryzen™ Master Support: Yes
• CPU Socket AM5
• Supporting Chipsets
  X670E
  X670
  B650E
  B650
• CPU Boost Technology Precision Boost 2
• Instruction Set x86-64
• Supported Extensions AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
• Thermal Solution (PIB) AMD Wraith Prism
• Max. Operating Temperature (Tjmax) 95°C
