Frequency
|
Insertion Loss (IN-OUT) dB
|
Tap Loss (IN-TAP) dB
|
Isolation (TAP-TAP) dB
|
Isolation (OUT-TAP) dB
|
Return Loss(OUT) dB
|
5 - 40 MHz
|
=9.0
|
16±1.5
|
=38.0
|
=26.0
|
=16.0
|
40 - 470 MHz
|
=9.5
|
16±1.5
|
=40.0
|
=25.0
|
=16.0
|
470 - 862 MHz
|
=10.0
|
16±2.0
|
=38.0
|
=23.0
|
=16.0
|
862 - 1000 MHz
|
=11.0
|
16±2.0
|
=34.0
|
=21.0
|
=16.0
|
Mechanical Specifications
|
|
Impedance In/Out, Ohm
|
75
|
CE Compliance
|
Class A
|
Temperature Range
|
Operating: -20°C to +60°C, Storage: -40°C to +70°C
|
In/Out Connector
|
F Female
|
Dust & Water Ingress Protection Rating
|
IP20 Minimum
|
Housing
|
Zinc Die Cast, Bright Tin Finish and Solder Shield Bottom Plate.
|
Grounding Screws
|
±PM 3×6 A3 nickel-plated 2 pieces
|
Wall Mounting Screws
|
±PA 4×18 A3 nickel-plated 2 pieces
|
Grounding Terminal Connection
|
Yes
|
