Features:
Improves data throughput and range over existing 802.11b/g products
Add high-speed Wireless-N (draft 802.11n) Internet access to any USB enabled computer
Download music & movies, surf the internet and e-mail up to 5 times faster than previous generation wireless networks (Wireless 802.11g)
Offers greater coverage than Wireless-G networks for internet access throughout your home or office
Works with older Wireless-G and Wireless-B networks
WiFi Protected Setup (WPS) simplifies setup and operation
Data transfer rate of up to 150Mbps (downlink) and 150Mbps (uplink)
Supports USB 2.0 interface, backward compatible to USB 1.1 and 1.2
Enhanced WEP and WPA wireless security for protected Internet access
64-bit / 128-bit WEP (Wired Equivalent Privacy), TKIP, AES 2.400GHz ISM
Frequency Band Modulation Method: QPSK / BPSK / 16-QAM / 64-QAM
Supports Ad Hoc and Infrastructure modes
Supports IEEE 802.11e standard
Specifications:
Wireless Standards
IEEE 802.11n (draft)
IEEE 802.11g
IEEE 802.11b
Host Interface
High speed USB2.0/1.1 interface
Data Rate
802.11n: up to 150Mbps (downlink) and 150Mbps (uplink)
802.11g: 54 / 48 / 36 / 24 / 18/ 12 / 9 / 6 Mbps auto fallback
802.11b: 11 / 5.5 / 2 / 1 Mbps auto fallback
Frequency Band
2.4GHz ISM (Industrial Scientific Medical) Band
Chipset
Realtek RTL8188CUS
RF Frequency
2412 ~ 2462 MHz (North America)
2412 ~ 2472 MHz (Europe)
2412 ~ 2484 MHz (Japan)
Radio Channel
1 ~ 14 channels (Universal Domain Selection)
Range Coverage
Up to 3 times farther range than 802.11g
Antenna type
Integrated Antenna
Roaming
Full mobility and seamless roaming from cell to cell
RF Output Power
13 ~17 dBm (Typical)
Modulation
11n: BPSK, QPSK, 16QAM, 64QAM with OFDM
11g: BPSK, QPSK, 16QAM, 64QAM, OFDM
11b: DQPSK, DBPSK, DSSS, CCK
Data Security
64/128-bit WEP Encryption
WPA, WPA-PSK, WPA2, WPA2-PSK. TKIP/AES
Network
Auto-switch to use 802.11n or 802.11g or 802.11b mode
Supports Ad-Hoc, Infrastructure WLAN network
Wireless roaming
Data rate auto fall-back under noisy environment or longer range distance
Site Survey with Profile function
Configuration & Management
Plug-and-Play setup and installation
Media Access Control
CSMA/CA with ACK
LED Indicator
Link/Active ( Green )
