| Recording media |
microSD cards (64MB - 2GB), microSDHC cards (4GB - 32GB), microSDXC cards (48GB - 512GB) |
| Recording / playback formats |
|
| WAV (BWF) |
44.1k/48k/96k/192kHz, 16/24-bit, 32-bit float |
| MP3 |
44.1k/48kHz, 128k/192k/256k/320kbps |
| Number of channels |
|
| Input channels |
6 channels maximum |
| Recording tracks |
8 tracks maximum (6 tracks, stereo mix) |
| Analog audio input ratings |
|
| Mic inputs (unbalanced) |
|
| Input jacks 1-2(support plug-in power) |
|
| Connectors |
3.5mm (1/8") Mini TRS jacks |
| Maximum input level |
+1dBV |
| Minimum input level |
-69.3dBV |
| Input impedance |
85kΩ or higher |
| Mic inputs (balanced) |
|
| Input jacks 3-6(input set to "MIC") |
|
| Connectors |
XLR-3-31 equivalent(1: GND, 2: HOT, 3: COLD)
6.3mm(1/4") standard TRS jacksInput(Tip: HOT, Ring: COLD, Sleeve: GND)
Note: phantom power supported by XLR only |
| Maximum input level |
+2dBu |
| Minimum input level |
-75dBu |
| Input impedance |
2.2kΩ or higher |
| Input jacks 3-6(Input set to "LINE") |
|
| Connectors |
XLR-3-31 equivalent(1: GND, 2: HOT, 3: COLD)
6.3mm(1/4") standard TRS jacksInput(Tip: HOT, Ring: COLD, Sleeve: GND)
|
| Nominal input level |
+4dBu (GAIN:min) |
| Maximum input level |
+24dBu |
| Minimum input level |
-53dBu |
| Input impedance |
9kΩ or higher |
| Line input (unbalanced) |
|
| EXT IN jack |
|
| Connectors |
1/8" (3.5mm) Stereo Mini jack |
| Nominal input level |
-10dBV (GAIN:min) |
| Maximum input level |
+10dBV |
| Minimum input level |
-48dBV |
| Input impedance |
8.5kΩ or higher |
| Analog audio output |
|
| Line output (unbalanced) |
|
| LINE OUT jack |
|
| Connectors |
1/8" (3.5mm) Stereo Mini jack |
| Nominal output level |
-14dBV |
| Maximum output level |
+6dBV |
| Output impedance |
200Ω |
| Headphone output |
|
| Headphone jack |
|
| Connectors |
1/8" (3.5mm) Stereo Mini jack |
| Maximum output |
45mW + 45mW
(THD+N 0.1% or less, into 32Ω) |
| Built-in speaker |
0.4W (mono) |
| Control input/output ratings |
|
| USB port |
|
| Connectors |
USB Type-C |
| Format |
USB2.0 HIGH SPEED mass storage class |
| Bluetooth® device connector |
For Bluetooth® adapter (AK-BT1) only |
| Power |
4 AA batteries (Alkaline, Ni-MH or Lithium-ion)
USB bus power from a computer
TASCAM PS-P520U AC adapter (sold separately) |
| Power consumption |
7.5W (maximum) |
| Dimensions |
83 (W) × 205.6 (H) × 41.5 (D) mm
※including protrusions |
| Weight |
472g / 381g (with/without batteries) |
| Operating temperature range |
0 - 40°C |
| Included |
Included mics × 1 (left / right pair)
AA alkaline batteries × 4
Owner's Manual (including warranty) × 1
TASCAM ID registration guide × 1 |
